Additional information
Applicable to | Mitshubishi, Solè, Vetus |
---|---|
Voltage DC | 12v |
Ampère | 40 A |
Mounting ear width | 16.75 mm |
Suspension distance | 41.00 mm |
Tachometer connection | W |
Original price was: €289,95.€198,95Current price is: €198,95.
Includes 21% Tax
Product ID: 25063
✓ 1 pieces shipped the same day, if ordered on workdays before 15:30 (pick-up possible, after ordering)
+ 21 pieces shipped within 24 hours, if ordered on workdays before 15:30 (pick-up possible from the next workday if ordered before 15:30)
Specifications
Voltage: 14
Amp: 40
Terminal: W (rev-counter)
Blower: Internal fan
Pulley: V-Groove
A Pulley distance: 42.00
B Width holder arm: 16.75
C Mounting bracket dist.: 41.00
D Bracket hole: 8.50
E Pos. belt adj. bracket hole: 60
G Belt. adj. bracket hole: M8
H Diameter pulley: 70.20
I Grooves/pulley: 1
J Radius 1: 74.45
J Radius 2: 70.00
K B+ position: M6
O Regulator plug: PL0
Replacing Vetus: STM1243
Servicing Vetus: M2.04, M2.05, M2.06, M2.C5, M2.D5, K4E, K4M, L3C, L3E
Servicing Sole: Mini 11 Mini 17, Mini 26, Mini 29, Mini 48,
SOL DIESEL Mini-11
SOL DIESEL Mini-17
SOL DIESEL Mini-26
SOL DIESEL Mini-48
Vetus Marine M2.05 Replacement!
VETUS MARINE M2.06 (Mitsubishi)
VETUS MARINE M3.10 (Mitsubishi)
A000T25171
A000T25271
A000T25371
A000T25373
a0t25171
a0t25271
a0t25371
a0t25373
MM432804
mm435081
mm435752
mm438844
MM131020,
MM432804,
MM435081,
MM435751,
MM435752,
Lester 12231
WAI 12231N
Vetus STM1243
Sole Diesel 13827210
Product ID: 25063
Applicable to | Mitshubishi, Solè, Vetus |
---|---|
Voltage DC | 12v |
Ampère | 40 A |
Mounting ear width | 16.75 mm |
Suspension distance | 41.00 mm |
Tachometer connection | W |
