Additional information
Voltage DC | 24v |
---|---|
Fitting edge | 88.80 mm |
Spacing holes | 127.00 mm, 90.00 mm |
Bendix distance | 28.50 mm |
Amount of teeth | 10 |
Gear diameter | 39.00 mm |
€373,79
Includes 20% Tax
Product ID: 35102
✓ 31 pieces shipped within 24 hours, if ordered on workdays before 15:30 (pick-up possible from the next workday if ordered before 15:30)
Electrical specifications
Voltage: 24
kW: 4.0
Physical Specifications
H No. of teeth: 10
P Rotation: Clockwise
N Gear type: Conventional
A Mounting flange: 88.80
I B+: M10
No. of mounting holes: 3 (0)
B Drive distance: 28.50
E Mounting holes: 11.00
E Mounting hole 2: 11.00
E Mounting hole 3: 11.00
F Distance rear in mm: 252.00
G Distance front: 76.00
M Mounting bracket: No
O Distance mm: 90.00
O Distance 2: 127.00
O Distance 3: 90.00
R Total length mm: 341.00
Replacing:
1368026 Bosch
1368040 Bosch
1368051 Bosch
11.130.993 Iskra
27301K Lucas
27309 Lucas
27309A Lucas
27309E Lucas
27311 Lucas
27311A Lucas
27311E Lucas
27311H Lucas
27315 Lucas
27315A Lucas
27315B Lucas
27315E Lucas
2873306 Massey Ferguson
2873K063 Perkins
3091293M92 Massey Ferguson
5000383929 Renault
AZJ3351 Iskra
F005510 John Deere
OR1903 Caterpillar
Product ID: 35102
Voltage DC | 24v |
---|---|
Fitting edge | 88.80 mm |
Spacing holes | 127.00 mm, 90.00 mm |
Bendix distance | 28.50 mm |
Amount of teeth | 10 |
Gear diameter | 39.00 mm |
