Additional information
Applicable to | Yanmar |
---|---|
Voltage DC | 12v |
Fitting edge | 69.90 mm |
Spacing holes | 109.70 mm |
Bendix distance | 17.50 mm |
Amount of teeth | 9 |
Original price was: €239,95.€196,95Current price is: €196,95.
Includes 21% Tax
Product ID: 27885
✓ 1 pieces shipped the same day, if ordered on workdays before 15:30 (pick-up possible, after ordering)
+ 81 pieces shipped within 24 hours, if ordered on workdays before 15:30 (pick-up possible from the next workday if ordered before 15:30)
Electrical specifications
Voltage: 12
kW: 1.0
Physical specifications
A Mounting flange: 69.90
B Drive distance: 17.50
H No. of teeth: 9
I B+: M8
N Gear type: Direct drive
O Distance: 109.70
P Rotation: Clockwise
R Total length: 217.00
Further information
No. of mounting holes: 2 (0)
Drive type: Steel
Oil sealed: No
Waterproof: No
Servicing
Yanmar 1GM10, 1GM10C, 1GM10, 1GM10VE
Yanmar 2GM20, 2GM20, 2GM20F, 2GM20FC
Yanmar 3GM30, 3GM30VE, 3GM30B, 3GM30C, 3GM30F, 3GM30FVE
Replaces
s114-303
s114-303a
128170-77010
128170-77010d
128170-77010
S114-303
S114-303A
LRS1128
LRS01128
WAI 18209N
Product ID: 27885
Applicable to | Yanmar |
---|---|
Voltage DC | 12v |
Fitting edge | 69.90 mm |
Spacing holes | 109.70 mm |
Bendix distance | 17.50 mm |
Amount of teeth | 9 |
